AD84C01KNX Multifunctional module

Type: eelectron AD84C01KNX Multifunctional module - 4 digital
inputs, 4 inputs that can be configured as digital or analog for reading temperature probes and 4 outputs for LEDs.

GTIN: 8054144520841

Bus System: KNX

Degree of protection: IP20

Installation: Recessed

The AD84C01KNX module contains 4 digital inputs for connecting dry potential contacts and 4 analog or digital inputs for potential-free contacts or temperature sensors and 4 LED outputs. Digital inputs can connect sensors, traditional buttons, etc.; 4 low voltage/current outputs can power LEDs for synoptic panels or switches. Inputs 5 ÷ 8, set as analog inputs, can allow up to 4 temperature probes (with on/off threshold) and 4 thermostats to control heating and cooling devices, valves, 2 and 4-pipe fan coils; etc.. The device is equipped with an appropriate communication interface with a TP1 (twisted pair) KNX European standard bus, according to CEI EN 50090.

Link to manufacturer informations

Link to manufacturer informations 2

The price and the possibility to purchase a product from the eelectron brand will be displayed after logging in.

Estimated delivery time: 2 - 4 weeks (depends on quantity, contact us for more accurate information).
